Available Options:
- Base Plate – Thickness -12 MM
- Frame (Pedestal) Made of 1st Quality TATA Heavy-duty 130 MM Hollow Pipe & 5”Channels
- Shaft –EN-8, Hardened Edge with Steel Ball for Longer Life – 60 MM
- Upper Bearing Housing- Heavy Duty, Having Double Bearing No. 6312 & 22212.
- Lower Bearing Housing – Heavy Duty, Hardened &Double Bearing SKF No. 6209,
- Heavy duty Spiral Bevel Gear Suitable for above mill 90 degree input 15 HP 960 RPM 1:2.2 ratio., hollow output. Complete with Coupling and Main Shaft
- Conical Hopper, screw feeder, PBL make Geared motor and Grain level Sensor and Alarm with Control Panel (for Grain feeder Only) with VFD controller
- Bharat Bijali Motor with coupling
| Size | 1200MM |
|---|
